Siemens SINAMICS V90 Servo Drive 0.4 kW 200 V PTI (Pulse/USS/Modbus) – 6SL3210-5FB10-4UA1

Name: Siemens V90 0.4kW Servo Drive 6SL3210-5FB10-4UA1
SKU: 6SL3210-5FB10-4UA1

Siemens SINAMICS V90 0.4 kW servo drive (6SL3210-5FB10-4UA1) for 200–240 V 1/3AC, with pulse train input, USS/Modbus RTU, internal position, speed and torque control, and integrated STO.

TBA

Price (incl. VAT)

Brand	Siemens
Series	SINAMICS V90
Product Type	AC servo drive – pulse train input (PTI) version
Model	SINAMICS V90 PTI, 200 V variant, frame size FSB
Part No	6SL3210-5FB10-4UA1
Max. Motor Power	0.4 kW
Line Supply	200–240 V 1AC / 3AC, -15% / +10%
Line Frequency	50/60 Hz (-10% / +10%)
Input Current	5.0 A (1AC) / 3.0 A (3AC)
Line Supply Capacity	1.2 kVA (1AC) / 1.1 kVA (3AC)
Rated Output Current	2.6 A
Max. Output Current	7.8 A
Overload Capacity	300% of rated current for 300 ms, every 10 s
Control Modes	External pulse position (PTI), fast PTI, internal position (IPos), speed (S), torque (T) and compound modes
Pulse Train Input	2 channels: 5 V differential line driver (max. 1 MHz) or 24 V optocoupler (max. 200 kHz), one usable at a time
Electronic Gear Ratio	A/B, A and B 1–65535, 1/50 < A/B < 200
Encoder Pulse Output	5 V differential, A/B/Z phase
Digital Inputs / Outputs	10 DI (NPN/PNP) / 6 DO (NPN)
Analog Inputs / Outputs	2 analog inputs (AI1, AI2) / 2 analog outputs ±10 V, 10-bit
Communication	USS / Modbus RTU via RS485
Other Interfaces	Mini-USB port, micro SD card slot, integrated operator panel
Safety Function	Safe Torque Off (STO) via terminals – SIL 2 (EN 61508), PL d Cat. 3 (EN ISO 13849)
Braking Resistor	Integrated
Tuning	One-button tuning and real-time auto-tuning
Compatible Motors	SIMOTICS S-1FL6 servo motors (encoder resolution up to 21-bit)
Cooling	Natural cooling
Degree of Protection	IP20
Dimensions (W × H × D)	55 × 170 × 170 mm
Weight	Approx. 1.2 kg
Ambient Temperature	0 to 45 °C without derating (up to 55 °C with derating); storage -40 to +70 °C

Product Overview

The Siemens SINAMICS V90 6SL3210-5FB10-4UA1 is the 0.4 kW, 200 V servo drive from the pulse train input (PTI) version of the SINAMICS V90 family. It runs on a 200–240 V single-phase or three-phase supply, delivers 2.6 A rated and 7.8 A maximum output current, and is built in the compact FSB frame (55 × 170 × 170 mm). Paired with a SIMOTICS S-1FL6 servo motor, it forms a cost-effective servo system for basic motion control tasks.

The PTI version accepts position setpoints as a pulse train from a PLC or motion controller (up to 1 MHz differential or 200 kHz at 24 V), and also offers internal position control, speed control and torque control with USS/Modbus RTU communication over RS485. Commissioning is simplified by one-button tuning and real-time auto-tuning, an integrated operator panel and a mini-USB port, while Safe Torque Off (SIL 2, PL d) and an integrated braking resistor are built in.
