Siemens SINAMICS V20 6SL3210-5BE17-5UV0 0.75 kW 3-Phase VFD

The Siemens SINAMICS V20 6SL3210-5BE17-5UV0 is a 0.75 kW variable-frequency drive for three-phase 380–480 V AC supply, rated 2.20 A output. It supports USS/Modbus RTU with a built-in operator panel and IP20 enclosure rating. This original UV0 unit is unfiltered and has no integrated braking chopper.

Model	6SL3210-5BE17-5UV0

TBA

Price (incl. VAT)

Brand	Siemens
Series	SINAMICS V20
Model	6SL3210-5BE17-5UV0
Part No	6SL3210-5BE17-5UV0
Rated Motor Power	0.75 kW / 1 HP
Input Phase	Three Phase (3P AC)
Input Voltage	380–480 V AC
Output Voltage	3P AC; 400 V IEC nominal / 480 V NEC
Rated Output Current	2.20 A
Output Frequency	0–550 Hz
Control Mode	Variable-speed control for three-phase asynchronous motors
Duty Rating / Overload Capacity	HO: 150% for 60 s / 300 s cycle; LO: 110% for 60 s / 300 s cycle
Built in Communication	USS and Modbus RTU over RS-485
EMC Filter	Unfiltered
Braking Configuration	No integrated braking chopper (FSAA)
Protection Rating	IP20 / UL open type
Supported Motor Types	3 Phase Asynchronous (Induction) Motors
Keypad / Operator Panel	Built-in Basic Operator Panel (BOP)
Dimensions (W × H × D)	90 × 150 × 145.5 mm

Siemens SINAMICS V20 6SL3210-5BE17-5UV0 0.75 kW 3-Phase VFD

Product identity and purpose

6SL3210-5BE17-5UV0 is a Siemens SINAMICS V20 basic AC variable frequency drive intended for adjustable-speed operation of suitably rated three-phase motors. This is the original UV0 ordering variant in the 380–480 V, three-phase-input family. It is a 0.75 kW drive with 2.20 A rated output, supplied without an integrated EMC filter. Its identity must be preserved when comparing replacement devices or reviewing technical drawings.

Electrical Ratings

The input is three-phase AC rated 380–480 V with a specified supply tolerance of −15%/+10% and nominal line frequency of 47–63 Hz. The older Siemens operating-instructions variant table identifies a 2.6 A rated input current, 2.2 A rated output current, and 2.2 A output at 480 V under the stated 4 kHz/40 °C conditions. The drive delivers three-phase variable-frequency voltage to the motor; it is not a single-phase-input converter. The motor nameplate current and application derating must be evaluated before selection.

Control Modes and Performance

SINAMICS V20 is a general-purpose speed-control drive with configurable ramping and basic application functions described in Siemens operating instructions. The Siemens product description states 150% overload capability for 60 seconds. Overload is temporary and must not be confused with the continuous 2.20 A output-current rating. Manufacturer operating conditions, load profile and cooling limits govern permissible use. The documented output frequency is 0–550 Hz; this is an electrical configuration capability, not permission to operate every motor or mechanical load at its maximum speed.

Communication and Configuration

The variant includes USS and Modbus RTU fieldbus support according to Siemens’ model description. Siemens identifies a built-in Basic Operator Panel (BOP), and the operating instructions describe drive parameterization and commissioning. A physical connector should not be assumed to indicate Ethernet capability. Selection of communication wiring, network settings and any additional external accessories should follow the applicable Siemens operating instructions.

Braking, EMC and Onboard Functions

The UV0 part is described as unfiltered, meaning an integrated EMC filter is not provided. Site-specific electromagnetic-compatibility measures may therefore require external filtering, screened motor wiring and appropriate grounding. The original UV0 generation is not specified with an integrated braking chopper; do not transfer the built-in braking feature of successor part 6SL3210-5BE17-5UV1 to this product. Do not assume an external braking resistor or braking assembly is supplied.

Installation and Typical Applications

The unit is IP20 / UL open type, frame size FSA, with manufacturer-listed dimensions 90 × 150 × 145.5 mm. Siemens documentation describes convection cooling for this version. Mount inside an appropriately protected industrial enclosure and maintain required mounting clearances, ventilation and thermal conditions. Use only with a compatible supply, motor and protective installation. Technically suitable examples include small conveyors, pumps, ventilation drives and similar variable-speed machinery after checking load torque, motor current, system protection and stopping requirements.

Exact Variant Verification

This workbook applies only to 6SL3210-5BE17-5UV0. It is distinct from the filtered 6SL3210-5BE17-5CV0 and from the newer 6SL3210-5BE17-5UV1, whose official description explicitly includes an integrated braking unit. Data from those related part numbers must not replace original UV0 ratings. The model’s lifecycle and successor reference should be checked directly before any replacement or retrofit decision.

Manufacturer Documentation

Official Manufacturer Product Page: https://mall.industry.siemens.com/mall/en/WW/Catalog/Product/6SL3210-5BE17-5UV0

Official Manufacturer Datasheet / Technical Documentation: https://mall.industry.siemens.com/spice/docuservice/rest/document.spring?articleNumber=6SL32105BE175UV0&documentGroup=TED&documentId=DCS_DATASHEET_PMD_CLEANED&language=en&region=ww

Siemens Operating Instructions (2020): https://support.industry.siemens.com/cs/attachments/109780683/V20_op_instr_0520_en-US.pdf

Similar Products

SINAMICS V20 VFD:https://plcstorebd.com/product-category/vfd/siemens-vfd/

• Siemens SINAMICS V20 original UV0 0.75 kW AC drive
• Three-phase 380–480 V AC input, −15%/+10% tolerance
• 2.20 A continuous rated output current
• USS and Modbus RTU communication supported
• Built-in Basic Operator Panel for commissioning
• 150% overload for 60 seconds
• Unfiltered; no integrated EMC filter
• IP20 / UL open type, FSA; no integrated braking chopper

• Small conveyor speed control with compatible motors and load
• Small industrial pump speed adjustment, subject to motor sizing
• Ventilation and fan speed regulation after load verification
• Light-duty packaging and materials-handling machinery
• General machine speed control in protected industrial panels
• Small automated process equipment requiring adjustable motor speed
