Mean Well LRS-350-24 24V 14.6A 350W Switching Power Supply
MEAN WELL LRS-350-24 enclosed switching power supply, 24 V DC 14.6 A 350 W, with adjustable output, full protections and a slim 30 mm low-profile case.
TBA
Price (incl. VAT)
- 100% Original Products
- Official Warranty
- Fast & Safe Delivery
- Easy Returns (7 Days)
| Brand | MEAN WELL |
|---|---|
| Series | LRS-350 |
| Product Type | Enclosed Switching Power Supply (Single Output) |
| Model | LRS-350-24 |
| Part No | LRS-350-24 |
| Output Voltage | 24 V DC |
| Rated Output Current | 14.6 A |
| Current Range | 0-14.6 A |
| Rated Power | 350.4 W |
| Voltage Adjustment Range | 21.6-28.8 V |
| Voltage Tolerance | ±1.0% |
| Line / Load Regulation | ±0.5% / ±0.5% |
| Ripple & Noise (max.) | 150 mVp-p |
| AC Input Range | 90-132 V AC / 180-264 V AC (selected by 115/230 V switch) |
| DC Input Range | 240-370 V DC |
| Input Frequency | 47-63 Hz |
| Efficiency (typ.) | 88% |
| AC Current (typ.) | 6.8 A @ 115 V AC; 3.4 A @ 230 V AC |
| Inrush Current (typ.) | 60 A @ 115/230 V AC |
| Hold-up Time (typ.) | 16 ms @ 230 V AC; 12 ms @ 115 V AC |
| Overload Protection | 110-140% rated power, hiccup mode, auto-recovery |
| Overvoltage Protection | 28.8-33.6 V, hiccup mode, auto-recovery |
| Over-Temperature Protection | Yes, hiccup mode, auto-recovery |
| Cooling | Built-in fan with ON/OFF control |
| Operating Temperature | -25 to +70 °C (refer to derating curve) |
| Vibration | 10-500 Hz, 5 G, 60 min per axis |
| Withstand Voltage | I/P-O/P 3.75 kV AC; I/P-FG 2 kV AC; O/P-FG 0.5 kV AC |
| Safety Standards | IEC/UL 62368-1, EN 61558-1, EN 61558-2-16 |
| Dimensions (L x W x H) | 215 x 115 x 30 mm |
| Weight | 0.76 kg |
Product Overview
The MEAN WELL LRS-350-24 is a 350 W enclosed switching power supply delivering a regulated 24 V DC at up to 14.6 A. Part of MEAN WELL’s LRS series, it uses a slim 30 mm high metal case (215 x 115 x 30 mm) and accepts 90-132 V AC or 180-264 V AC selected by a 115/230 V switch, as well as 240-370 V DC, with a typical efficiency of 88%.
The output can be trimmed between 21.6 V and 28.8 V, and the unit is protected against overload, overvoltage and over-temperature with automatic recovery. A built-in fan with ON/OFF control, 5 G vibration resistance, -25 to +70 °C operating range and IEC/UL 62368-1 safety approval make the LRS-350-24 a dependable 24 V supply for control panels, LED systems, CNC machines and general industrial equipment.
Key Features
- 24 V DC output, 14.6 A, 350.4 W
- Output adjustable from 21.6 to 28.8 V
- AC input 90-132 / 180-264 V selectable by switch; 240-370 V DC
- Typical efficiency 88%
- Overload, overvoltage and over-temperature protection with auto-recovery
- Low-profile 30 mm height metal enclosure
- Built-in fan with ON/OFF control
- Withstands 5 G vibration; -25 to +70 °C operation
Applications
- Industrial control panels
- PLC and automation systems
- CNC machines and stepper/servo drivers
- LED signage and lighting
- 3D printers and laser equipment
- Security and CCTV systems
- Telecom and networking equipment
- Solenoid valves, relays and contactor coils (24 V)
